CONTROL PANEL
20
21
1
2
3
4
Fig. 1.1b
CONTROL PANEL - Controls description
5. Front left triple-ring burner control knob (4)
6. Rear left semi-rapid burner control knob (2)
7. Rear central rapid burner control knob (3)
8. Front central auxiliary burner control knob (1)
9. Front central hi-light cooking zone control knob (6)
10. Rear central hi-light cooking zone control knob (5)
11. Rear right semi-rapid burner control knob (2)
12. Front right triple-ring burner control knob (4)
17. Rear cooking zone residual heat indicator
18. Cooking zones control lamp
19. Front cooking zone residual heat indicator
20. Indicator light (bottom left oven)
21. Indicator light (top left oven)
5
6
7
8
19 18 17
9
10
11
12
136 PX 634
16
A
U
T
O
13
14 15
7
