Wheel 2x
Wheel Cover 2x
Self-Locking Nut M8 2x
Attach the two wheels to the bottom
shelf and secure them by use of
2 M8 self-locking nuts.
Tighten the self-locking nuts until
they are level with the axle.
Attach the wheel covers to the
wheels afterwards.
Screw M6x25
Washer 3x
Turn the grill assembly into an
upright position by holding it on the
legs and place it so that the wheels
are in the back.
Attach the legs to the firebox
thought the centre hole of the grate
holders by use of 3 M6x25 screws
and 3 washers .
7
2x
Wheel Wheel Cover
2x
Nut
8
3x
M6x25
3x
3x
Washer
2x
