Programming a sequence
of commands (Macro)
The MACRO key in coordination with one of the keys
1, 2, or 3, allows the programming and memorisation
of up to 3 command sequences (the automatic and
successive pressing of several keys of your choice). Thus
any sequence of key commands can be reduced to
merely 2 commands (MACRO key + key 1, 2, or 3).
For example after programming, by pressing MACRO
then key 1 you could turn on your television set, turn on
your satellite or cable receiver, zap to a preferred
channel, turn on your video cassette recorder and start
a recording session (providing a cassette was
previously loaded). You can memorise a sequence of
10 commands with each key 1, 2, or 3.
Note: during the programming of a macro, the time
between each step is limited to a few seconds. This
leaves little time for reading the instructions and then
carrying them out. If the mode indicator light blinks
and then goes out, it is because this time limit has
been exceeded, you must start again from step 1.
To record a MACRO:
1. Press and hold down the SETUP key until a (TV,
DVD, ...) mode key blinks and remains lit (after 2
or 3 seconds).
2. Release the SETUP key.
3. Press the MACRO key once. The mode key blinks.
4. Press once the 1, 2 or 3 key which you are going M1, M2 or M3
to use to memorise the sequence.
5. Press once on the (TV, DVD, ...) mode key of the
first device you wish to control (the first key must
always be a mode key.)
6. Successively press the keys corresponding to the
commands you wish to send to the device(s) (9 keys
maximum, including other mode keys). The mode
key blinks when each key is pressed.
7. Memorise your key sequences by pressing the
MACRO key once. The mode key is no longer lit
and your Macro is complete.
Note: a sequence will be automatically memorised
after the tenth key press (counted from the mode key)
and the mode key light will go out.
To use a MACRO:
Press the MACRO key once and, within 20 seconds,
press the 1, 2 or 3 key you used to memorise the
sequence.
Note: when running a Macro (which takes a few
seconds), ensure that the remote control is aimed at
the device being controlled.
Remarks:
• The default time between sending 2 commands when
using a macro is half a second.. However, it is
possible that you will need to add longer periods in
your sequence in order to allow enough time for
certain devices to turn themselves on. To lengthen the
time period between 2 commands, press once on the
K key and then press one of the keys from 1 to 9 in
order to insert a pause from 1 to 9 seconds.
• The first key in a sequence must always be a mode
key ( TV , DVD , ...).
Note: the indications TV , DVD , STB (below keys 1 ,
2 , 3 ) are only an aid to memory. You may decide, for
example, to memorise a MACRO for the television
set using key 1 , etc.
Deleting a MACRO:
1. Press and hold down the SETUP key until the (TV,
DVD...) mode key blinks and then remains lit (after
2 or 3 seconds).
2. Release the SETUP key.
3. Press once on the MACRO key. The mode key
begins to blink.
4. Press once the 1, 2 or 3 key that represents the
sequence to delete.
5. Press and hold down the SETUP key. The mode key
light goes out and the sequence is now deleted.
M1, M2 or M3

Other functions

Placing all devices on standby
Press the G key twice in less than one second, keeping
it held down the second time. All the devices go on
standby one after the other (the devices which were
already on Standby may turn on).
Adjustment of ALL volume controls under a
specific mode
In its delivered state, the ROC4411 is programmed
such that all modes will use their own Volume and
Mute functions if present.
You can allocate the volume control to one of the
modes of the remote control on condition that the
volume control exists on the corresponding device
(e.g. control of TV sound in TV mode, DVD mode,
Mode, etc.).
1. Hold the SETUP key down until the indicator lamp
blinks and then remains lit.
2. Release the SETUP key
3. Press the H key until the indicator lamp blinks
once.
4. Press once on the mode key (TV, DVD, ...)
corresponding to the device whose volume will
always be controlled by the VOL and H keys.
5. Press the H key once. The indicator lamp goes off.
6. All other mode will now punch-through to your
chosen mode for Volume and Mute control.
Adjustment of the volume controls for EACH
mode.
You can decide that the volume control is functional
for each mode selected on condition that the volume
control exists on the corresponding device (e.g. control
of the television set sound in TV mode, the control of
the sound of the SAT receiver in SAT/STB mode, ...).
1. Hold the SETUP key down until the indicator lamp
blinks and then remains lit.
2. Release the SETUP key
3. Press the H key until the indicator lamp blinks
once.
4. Press once on the mode key (TV, DVD, ...)
corresponding to the device whose volume will
always be controlled by the VOL and H keys.
5. Press the VOL- key once.
6. Press the H key once. The indicator lamp goes
off.
7. The chosen mode key will now use its own Volume
and Mute functions
Restoring the universal Volume/Mute
functions
If you have changed the universal volume and mute
functions, as described in the previous two sections,
you can reset the functions back to the factory settings:
1. Hold the SETUP key down until the indicator lamp
blinks and then remains lit.
2. Release the SETUP key
3. Press the H key until the indicator lamp blinks
once.
4. Press and release the H key. The indicator lamp
will go off completely. The volume and mute
functions are now restored to their factory defaults.

Replacing the batteries

Replacing the batteries in the remote control
and in the base
Remote Control:
Use 2 AAA 1.5Volt batteries
1. Open the cover on the back of the remote control by
pushing down on the tab and lifting the cover off.
2. Check the +/– polarity on the batteries and inside
the compartment.
3. Insert the batteries.
4. Press the battery cover back into place.
When exchanging the batteries, it may be necessary to
reprogram the unit. Hence it is advisable to record the
codes needed for your devices.
