Operating Manual SATA filter 100 / 101 / 103 prep
US
Content [Original Version: German]
1. Symbols ................................ 248
2. Technical Data ...................... 248
3. Scope of Delivery ................. 249
4. Technical Design of the Filters 249
5. Intended Use ........................ 250
6. Safety Instructions ................ 250
7. Assembly .............................. 251
1.

Symbols

Danger! Risk which will cause heavy injuries or death.
Notice! Risk which could cause damage.
Information! Useful tips and recommendations
2.

Technical Data

Air inlet
Max. inlet operating pressure
Max. outlet operating pressure
Max. ambient temperature
Air flow at 87 psi
Weight of SATA filter 100 prep
Weight of SATA filter 101 prep
Weight of SATA filter 103 prep
248
8. Use ....................................... 251
9. Function ................................ 252
10. Maintenance ......................... 253
11. Troubleshooting .................... 254
12. Disposal ................................ 255
13. After Sale Service ................. 255
14. Warranty / Liability ................ 256
15. Spare parts ........................... 256
G ½" (internal thread)
145 psi
145 psi
122 °F
< 28.3 cfm
2.8 kg
1.3 kg
4.1 kg
