INSTALLING
INSTALLATION PROCEDURE
Warning: keep module and charge point switched off during installation.
To complete an installation, proceed as follows:
1.
Don't plug the power adapter in the power outlet yet.
2.
Connect the power adapter to the P1 current sense module.
3.
Connect the CT('s) to the P1 current sense module.
4.
Install the P1 current sense module on the DIN Rail in the fuse box.
5.
Apply the CT('s) to the grid connection(s). Make sure to apply the CT(s) so that the total
power usage per phase is measured.
6.
Plug the power adapter into a power outlet. The PWR LED must light up.
7.
The CS LED will (after a few seconds) indicate a measured current after the power is on.
8.
Prepare the cable between chargepoint and DPM module. The maximum length of the
cable between charge point and DPM module is 20 meters.
•
Home Advanced 2.1: the connectors should be attached straight wired with 6
wires and a RJ-12 connector.
•
Home Advanced 2.0: the connectors should be attached cross wired.
9.
Connect the RJ12 (6P6C) cable to the module. If the other end of the cable is already
connected to the charge point, the P1 LED will indicate whether the connection is
correct.
10. Contact New Motion for remote activation of DPM on number +44 (0)203 868 1036
Note 1: The P1 interface will be turned on 10 seconds after power up. During this period,
no P1 messages are sent and the P1 LED will not light up.
P-9 | ENGLISH | 0243NM11INT02
