► Digital display of Hours, Minutes and seconds ("S" option),
7-segment electroluminescent diodes.
► Tilt of figures: 10°.
► Power Supply:
Alternating current: 230 Vac (+/- 10%) / 50 - 60 Hz, 115 Vac (option)
Direct current (as option) : - 48 VDC : no polarity.
Power over Ethernet (option): POE, POE +.
► Consumption: 10 W on the average, varies according to model.
► Data saved with a built-in Lithium battery:
► 3-colour LED display (red/green/yellow). White or blue as optional feature.
► Visual indication of the status of sync via the two second dots (except standalone version)
LEDI range: Standard case – Wall or flush mounted
®
LEDI REVERSO and LEDI
®
with ceiling or side bracket

2.1. AVAILABLE VERSIONS (ACCORDING TO MODEL):

2.1.1. Standalone version:

Built-in 32-KHz TCXO quartz time base

2.1.2. Parallel minute impulse input:

1-minute impulses - Inverted 24V per minute.
Duration of impulse: 0.1sec to 5 sec.
Impulse consumption: 6 mA/24V
Extinction of the two second dots: 120 seconds without synchronization
2.1.3. Series connection ½-minute impulse input:
Series connection with an external 39-Ohm shunt.
½ minute impulses - Inverted every ½ minute.
Duration of impulse: 0.1 sec. to 5 sec.
Impulse consumption: 1.25 V
Line intensity: 60 mA to 120 mA
Extinction of the two second dots: 60 seconds without synchronization
MDE-LEDI-1099V3.4
2. GENERAL
- 24 VDC, 12 VDC : "+" = brown wire; "-" = blue wire".
POOL range: Single or dual sided - Wall Mount - Mounting
®
CHARACTERISTICS
