If using a 230Vac 50Hz power supply, do not connect in series more than 7 units,
use another mains supply for the next 7 units.

2. Technical Specification


It can be operated by DMX512 control or can be used as an individual unit without
controller.

Please use a 3 pin XLR cable/plug when link in master/slave mode.

LED: 50W white LED

Voltage: AC 230V/50hz

Fuse: T 6.3 A

Power Consumption: 89.2 W

Dimension: 286 x 377 x 218 mm

Weight: 5.2kgs

3. Installation

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit
is firmly fixed to avoid vibration and slipping while operating. Always ensure that the
structure to which you are attaching the unit is secure and is able to support a weight of 10
times of the unit's weight. Also always use a safety cable that can hold 12 times of the
weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where is out
of the touch of people and has no one pass by or under it.

4. How To Set The Unit

4.1 Control Panel
