Unpacking
1. Remove packing materials from unit.
NOTE: Save all packing materials until you are completely satisfied all parts of
the unit are operating satisfactorily and just in case the unit should need
service in the future.
2. Make sure you have located the Remote Control before storing the packaging.
3. Remove the plastic bag covering the unit.
4. Remove the plastic safety cover from the AC 3-pin plug.
5. Remove the tie from the AC cord and untie the Wire Antenna on the back of the unit.
6. Lift up the Record Player Lid and remove the Polystyrene shipping material from the turntable.
7. Remove the black tie-wire from the Tone arm.
8. Remove the white protective needle cover by gently pulling it towards the front of the unit.
Stylus
A universal Sapphire Stylus is supplied and fitted to the Tone Arm, this is suitable for playing records
of all 3 speeds (331/3/45/78rpm). A replacement universal stylus and a separate stylus for playing
78rpm records are available direct from the Manufacturer and some Dealers.
Removing/Refitting the Stylus
To remove the Stylus from the Tone Arm, hold the Tone Arm
head steady while grabbing the plastic Stylus Holder with
two fingers - then gently pull the complete red stylus holder
straight towards you and off the silver cartridge, as shown
in the diagram.To re-fit the Stylus, hold the sides of the red
plastic stylus holder, ensuring the Needle is facing downwards.
Gently push the back of the stylus holder at a slight angle against
the silver cartridge at the end of the TONE ARM until you are sure
it is securely fitted. Refit the white protective needle cover, if so required.
Notes
· Always handle the Stylus with care as the Sapphire needle tip is easily damaged.
· When transporting the turntable it is advisable to re-fit the white protective needle cover and the
Tone Arm Hold-down Clip until the unit is going to be used again.
· When removing or re-fitting the Stylus, always be careful not to put too much pressure on the Stylus
Holder and the Tone Arm silver cartridge to avoid any possible damage to them.

Power source

This unit is operated by 230V AC Mains.
NOTES:
a) ESD remark: In case of a malfunction due to electrostatic discharge, you may need to re-set the
product to resume normal operation (re-connection to the power source may be required).
b) Electrical Fast Transient (Burst) : In case of a malfunction due to electrical fast transient (Burst),
just reset the product to resume normal operation (re-connection to the power source may be
required).
