CASA R4-C GENIUS
Installation and commissioning instruction
Notice d'installation et de mise en service
The delivery includes
• Ventilation unit
• Mounting brackets, 4 pcs.
• Cover plugs, 3 pcs.
• Quick Guide
• Installation and commissioning instruction
Standard connections
• Power cord with earthed plug (6.6 ft | 2 m)
• Cable for SEC/SEM connection module with RJ45
connector (6.6 ft | 2 m)
• Modular cable with RJ9 connector (4.9 ft | 1.5 m)
• Freely configurable I/O contacts for connection of
accessories (2 pcs.)
Area of air flow operation
Product | Produit
CASA R4-C Genius R ex.el RH NA
CASA R4-C Genius R ex.el RH NA Sorption
NA_R4C_d-i
Air flow range
Plage de débit d'air
CFM
l/s
42 - 195
20 - 92
85 - 195
40 - 92
eManual
Inclus à la livraison
• Unité de ventilation
• Consoles, 4 pces
• Embouts, 3 pces
• Tableau de sélection rapide
• Instructions d'installation et de mise en service
Raccords standards
• Cordon d'alimentation avec prise de terre (6.6 ft | 2 m)
• Cable du module de raccordement SEC/SEM avec
connecteur RJ45 (6.6 ft | 2 m)
• Câble modulaire avec connecteur RJ9 (4.9 ft | 1.5 m)
• Contacts I/O configurables librement pour raccordement
d'accessoires (2 pces)
Zone d'opération débits d'air
Unit ambient temp.
Temp. ambiante de l'unité
°C
°F
+10 - (+50)
+50 - (+122)
+10 - (+50)
+50 - (+122)
Swegon CASA App
Outdoor air temp.
Temp. de l'air extérieur
°C
°F
-20 - (+50)
-4 - (+122)
-15 - (+50)
+5 - (+122)
