Instruction CF-RC Remote Controller
2. Installation
Note:
• Install the Remote Controller after you have installed all the Room Ther-
mostats, see g. 5 b
• Remove the strip to connect the enclosed batteries
• Carry out the assignment of the Remote Controller to the Master Control-
ler within a distance of 1,5m
• When the back light in the display is out, the rst touch of a button only
activates this light
Activate Install mode on the Master Controller - g. 3
• Use the menu selection button
install LED
• Activate Install mode by pressing OK
Activate Install mode on the Remote Controller
• When the batteries have been connected, follow the installation
guide, beginning with the selection of language
• After the installation process, set time and date. Use the up/down
selector
1). Con rm settings with OK activated by soft key 1 ( g. 1-
• The installation process is concluded with the opportunity to name
the rooms in which the Room Thermostats are placed. This makes ac-
cess to and handling of the system very easy
• In the Name rooms menu, activate the change menu with soft key
2 ( g. 1-
1.2 (Master Controller 1, output 1 and 2) to living room, and con rm
with OK. You can also use the spell.... menu to create other names
6
VI.UH.M2.52
ashes
and the left/right selector
) to change the default room names from e.g. MC1 Output
Produced by Danfoss Floor Heating Hydronics 09.2005
to select the Install mode. The
. The install LED
to carry out the settings ( g.
goes ON
)
