TECHNICAL DATA
Max. speed
Max. roller shutter blind surface
End pulling force
Short-term operation
Protection class
Protection class
Positioning precision
Number of switching times
Automatic sunlight control adjust-
ment range
Permissible ambient temperature
Clock accuracy
Dimensions
Permissible belt widths
Belt length
(15 mm standard belt)
Sound pressure level
Note:
The specifications provided are recommended values and apply to ideal installation situations. Due to
existing site conditions, the values may be different.
Only use the product in combination with shutter belts with the dimensions mentioned above. Wrong
shutter belt lengths and widths will result in damage. Replace the old shutter belt when the require-
ments are not met.
34 rpm
4.0 m
(3 kg/m
roller shutter blind
2
2
surface)
7 kg on belt
5 minutes
II
IP 20 (only for dry rooms)
5 mm
2 (UP and DOWN)
3,000 to 10,000 lux
0-40 °C
Approx. +/- 1 minute / month
See page 186
23 mm maxi
5.5 m for 1.0 mm belt thickness
4.3 m for 1.3 mm belt thickness
LpA < _ 70 dB(A)
16
