Installation
Align the mounting brackets horizontally by sliding
them back and forth along the screw slots until
the brackets are exactly 27-1/2" apart and equal
distance from the cabinet sides. See figure 7.
Once the brackets are correctly positioned,
securely tighten the four (4) screws B.
Cabinet Installation
STALL
Place the oven adjacent to the wall or cabinet
opening. Plug the power cord into the electrical
outlet.
opening. Slide the oven onto the Bottom Duct Assembly.
Avoid pinching the cord between the oven and the wall.
Adjust the position of the oven so that the feet of the oven
are fitted into the recesses of the Bottom Duct Assembly.
CABINET INSTALL
8
CABINET INSTALL
Carefully guide the assembled oven into the prepared
See figure 8.
9
See figure 9.
Frame Assembly
Turn over FRAME ASSEMBLY to locate the 4 ball
studs.
!
Position the FRAME ASSEMBLY with the small
stainless decorations on top. Align the 4 ball studs
with the 4 snap attachments at both ends of the
MOUNTING BRACKETS.
Secure the FRAME ASSEMBLY by firmly pushing
it onto the Mounting Brackets engaging the four
(4) snap attachments. See figure !.
FOOT
BOTTOM
DUCT
ASSEMBlY
DUCT RECESS
7
4 BAll STUDS ON BACK OF FRAME ASSEMBlY
SMAll STAINlESS DECORATIONS ON TOP
FRAME INSTALL
SNAP ATTAChMENT lOCATIONS ON
MOUNTING BRACKETS
E
