iM3 SILENT HURRICANE II Serie Manuel D'instructions page 11

USER'S MANUAL
UNIT'S REAR OPERATIONAL ELEMENTS
ULTRA SONIC COOLANT
PET PRESSURE
COOLANT BOTTLE
AMBER - for CLS solution
With the coolant bottle pressure switch in the "ON" position, the bottle will be pressurized between 26-28 PSI (approx. 2.5 bar)
to supply Water/CLS to the 3 way syringe and the High Speed Handpiece. It must be switched to the OFF position to
release the pressure before re-filling the bottle.
1. Ultra Sonic Coolant outlet – This will supply pressurized water/CLS to your ultrasonic dental scaler – A male fitting can
be supplied by iM3 for your ultrasonic scaler water line. DO NOT use any coolant other than distilled water or CLS –
any other solution may cause a blockage and will void your warranty.
2. A CLEAR PET pressure bottle is supplied. In an emergency situation, a new un-used bottle from iM3 is recommended,
anything else such as, a pre-used bottle could result in splitting, or could pass contaminants or bio-growth into the unit).
3. AMBER coolant bottle allows the use of CLS, which is light sensitive (contains chlorhexidine). The user can switch
between water and CLS.
GS DELUXE / (LED) VETERINARY DENTAL UNIT
OUTLET
MAIN POWER SUPPLY
IEC Male power cord is required.
Power board overload protector located inside unit.
11 � EN
MACHINE MAINTENANCE
INSTRUCTIONS
printed on back of machine
PET PRESSURE
COOLANT BOTTLE
CLEAR - for distilled water
