ASSEMBLY INSTRUCTIONS
1. Insert wood dowels (GG) into mounting cleats
(H).
Hardware Used
GG
Wood Dowel
2. Insert barrel nuts (HH), wood dowels (GG) and
large cam bolts (SS) into upper left side panel (A) and
upper right side panel (B) as shown. Then, attach
upper left side panel (A) and upper right side panel (B)
to lower left side panel (C) and lower right side
panel (D). Insert Cam locks (RR) into lower left side
panel (C) and lower right side panel (D) to secure
panel assembly.
Hardware Used
GG
Wood Dowel
HH
Barrel Nut
RR
Cam Lock
SS
Large Cam Bolt
3. Insert barrel nut (HH) into mounting cleat (H).
Secure mounting cleat (H), beveled edge down, to
upper right side panel (B) and lower right side panel (D)
where shown with lock washers (CC), small flat
washers (DD) and M6 x 60 mm bolts (BB). Then, attach
the middle fixed shelf (G) and top/bottom fixed shelf (E)
to upper right side panel (B) and lower right side panel
(D) with lock washers (CC), small flat washers (DD) and
M6 x 40 mm bolts (AA). Tighten all connections with
allen wrench (OO).
Hardware Used
AA
M6 x 40 mm Bolt
BB
M6 x 60 mm Bolt
CC
Lock Washer
DD
Small Flat Washer
HH
Barrel Nut
OO
Allen Wrench
1
x 4
H
GG
2
HH
x 4
GG
RR
x 4
x 4
SS
x 4
A
C
D
3
OO
AA
CC
BB
DD
CC
x 7
DD
x 1
AA
CC
x 8
DD
B
x 8
D
G
x 1
E
Beveled edge facing
x 1
bottom of unit
Lowes.com/allenandroth
6
ASSEMBLY INSTRUCTIONS
4. Repeat step 3 for upper left side panel (A) and
lower left side panel (C).
Hardware Used
AA
M6 x 40 mm Bolt
BB
M6 x 60 mm Bolt
CC
Lock Washer
DD
Small Flat Washer
HH
Barrel Nut
OO
Allen Wrench
5. Set assembly upright. Insert shelf pins (EE)
level where desired in tower, then rest adjustable
shelves (F) on top.
Note: Ensure the shelf pins (EE) are level.
Hardware Used
EE
Shelf Pin
B
6. Using a stud finder (not included), locate the edges
of the wood studs. Find the center line of each stud
and draw a vertical reference line on the wall over
each one. Position installation template (R) at desired
location on wall.
Note: The bottom of the installation template (R)
should be no less than 31-1/2 in. from the floor.
Mark mounting holes with a pencil (not included) and
HH
discard installation template (R). Drill 3/16 in. pilot
holes at marked locations. Then, with the beveled
H
edge facing up, attach the wall hanging cleats (I) with
E
large flat washers (JJ) and M8 x 2-1/2 in. lag bolts (II).
Hardware Used
II
M8 x 2-1/2 in. Lag Bolt
JJ
Large Flat Washer
4
x 7
A
x 1
C
HH
x 8
AA
DD
x 8
CC
x 1
DD
x 1
CC
BB
5
F
EE
x 8
F
EE
EE
6
Wooden Stud
16 in.
I
40.6 in.
R
x 4
Minimum 31-1/2 in.
x 4
Lowes.com/allenandroth
7
DD
CC
AA
OO
EE
JJ
II
I
JJ
II
