HARDWARE CONTENTS (shown actual size)
AA
M6 x 40 mm M6 x 60 mm
Bolt
Qty. 14
EE FF
Shelf Pin M3.5 x 12 mm
Wood Screw
Qty. 8 Qty. 8
II
M8x 2-1/2 in.
Lag Bolt
Qty. 4
OO
Allen Wrench Touch-up Pen
(not shown to size) (not shown to size, not
included for white color)
Qty. 1
RR
Cam Lock Large Cam Bolt
(not shown to size) (not shown to size)
Qty. 4
BB CC
Lock Washer
Bolt
Qty. 2 Qty. 16
GG
Wood Dowel
(not shown to size)
Qty. 8
JJ LL
Large Flat L-Bracket Wall Anchor
Washer (not shown to size) (not shown to size)
Qty. 4 Qty. 8
PP QQ
M4 x 38 mm
Screw
Qty. 1 Qty. 8
TT
SS
M4 x 14 mm
Wood Screw
Qty. 4 Qty. 24
Lowes.com/allenandroth
4
HARDWARE CONTENTS (for pole kit)
DD
MM
Small
Flat Washer
M4 x 14 mm
Zinc Wood Screw
Qty. 16
Qty. 6
HH
Barrel Nut
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
Qty. 6
the product.
• Do not allow children to climb or play in or around this product.
NN
• Use this unit for its intended purpose only. Do not use shelves as step ladder.
• To avoid damage, assemble the product on a sturdy, level and protective surface.
• Two or more persons must work together to install the unit onto the wall.
• Make sure all bolts/screws are tightly fastened before the unit is used.
• Check bolts/screws periodically and tighten them if necessary.
• Shelf maximum load: 30 lbs.
• Pole maximum load: 40 lbs.
Qty. 8
• Pole maximum length: 60 in.
WARNING
THIS UNIT IS INTENDED FOR USE ONLY WITH THE MAXIMUM WEIGHTS INDICATED. USE
WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHTS INDICATED MAY RESULT IN
INSTABILITY CAUSING POSSIBLE INJURY. DISTRIBUTE WEIGHT EVENLY.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included): Phillips Screwdriver, Power Drill, 3/16 in. Drill Bit, 3/8 in.
Drill Bit, 1/2 in. Socket Wrench, Level, Stud Finder, Marking Pencil, Tape Measure, Step Ladder, and
Hammer.
ZZ
YY
Open Pole Closed Pole M4 x 15 mm
Holder Holder Self-tapping Screw
Qty. 2 Qty. 2 Qty. 4
5
AB KK
M4 x 38 mm
Zinc Screw
Qty. 6
