3.2 PROBE - ELECTRODE POSITIONING
~
Probe
D5104
3.3 GAS FEEDING LINE
1
1 – Gas supply pipe
2 – Manual cock (supplied by the installer)
3 – Gas pressure gauge (supplied by the installer)
4 – Filter
5 – Gas pressure switch
6 – Safety valve
7 – Pressure governor
8 – Adjustment valve
20033828
47
mm
2
3
M1
Ignition electrode
Diffuser
–
3
2
WARNING
4
5
6
7
Gas-supply pressure test point
M1 –
M2 – Pressure coupling test point
4
GB
Ionization probe
Electrode
3.7
mm
8
D5099
=
M2
