Display channels
Channel Description
COL x Temperature collector
TSTB x Temperature store 1 base
TSTT x Temperature store 1 top
S4 x Temperature sensor 4
TFL x* Temperature flow sensor
TR x* Temperature return sensor
VFD x* Temperature Grundfos Direct Sensor™
L/h x* Flow rate Grundfos Direct Sensor™
n % x Speed relay
hP1 x Operating hours R1
hP2 x Operating hours R2
kWh x* Heat quantity in kWh
MWh x* Heat quantity in MWh
TIME x Time
Adjustment channels
Channel Description
Arr x System
PUM1 x Pump control type
nMN x Minimum speed R1
nMX x Maximum speed
DT1O x Switch-on temperature difference R1
DT1F x Switch-off temperature difference R1
DT1S x Set temperature difference R1
RIS1 x Rise R1
S1MX x Maximum store temperature 1
DT2O x Switch-on temperature difference R2
DT2F x Switch-off temperature difference R2
DT2S x Set temperature difference R2
RIS2 x Rise R2
S2MX x Maximum store temperature 2
EM x Collector emergency temperature
OCC x Collector cooling option
CMX x* Maximum collector temperature
OSYC x System cooling option
DTCO x* Switch-on temperature difference cooling
DTCF x* Switch-off temperature difference cooling
R1
R1
Connection terminal Page
S1 53
S2 53
S3 53
S4 53
S1 / S4 / VFD 53
53
S4 / VFD
53
VFD
54
VFD
R1 54
R1 55
R2 55
- 54
- 54
- 55
Factory setting Page
4 55
PSOL 57
30 % 57
100 % 57
6.0 K [12.0 °Ra] 56
4.0 K [8.0 °Ra] 56
10.0 K [20.0 °Ra] 56
2 K [4 °Ra] 56
60 °C [140 °F] 56
6.0 K [12.0 °Ra] 56
4.0 K [8.0 °Ra] 56
10.0 K [20.0 °Ra] 56
2 K [4 °Ra] 56
60 °C [140 °F] 56
130 °C [270 °F] 56
OFF 58
110 °C [230 °F] 58
OFF 59
20.0 K [40.0 °Ra] 59
15.0 K [30.0 °Ra] 59
25
