Technical Data
Battery Charger
Article number
Rated voltage
Frequency
Output voltage
Charging current
Charging time, approx.
– PowerPack 400
– PowerPack 500
Operating temperature
Storage temperature
Weight, approx.
Degree of protection

Operation

Initial Operation
Connecting the Charger to Household Electricity
2
 Note the household voltage! The voltage of the power
supply must correspond to the specifications given on
the battery charger nameplate.
Plug the charger plug 3 of the power cord into the charger
socket 2 of the charger.
Connect the power supply cable (country-specific) to the
household electricity supply.
Use only the supplied input connection: standard AC power
cord (3 in the diagram) when connecting to the household
electrical supply.
Bosch eBike Systems
Wide Range Charger (36–4/100-230)
V~
Hz
V
A
h
h
°F
°F
lb
2
3
199
Compact Charger (36–2/100-240)
0 275 007 906
90...264
47...63
36
4
3.5
4.5
+32...+104
+14...+122
1.8
IP 40
Charging the Removed Battery
11
6
5
5 Charge connector
6 Socket for charge connector
8 Rack-type battery pack
9 Operation and charge-control indicator
10 Battery On/Off button
11 Standard battery pack
Switch the battery pack off and remove it from the holder of
the eBike. To do this, read and follow the operating instruc-
tions for the battery pack.
 Put the battery pack down only on clean surfaces. In
particular, avoid getting the charge socket and the con-
tacts dirty, e.g., with sand or soil.
Insert the charger plug 5 for the battery charger into the
socket 6 on the battery pack.
English–6
0 275 007 915
+32 ...+104
+14 ...+122
9
8
6
0 275 U07 XCX | (25.4.16)
90...264
47...63
36
2
6.5
7.5
1.3
IP 40
