Meaning of the symbols
doorbell
telephone
person call
babycry
fire alarm
alarm
Checking the last signal, can-
celling the current signal
By pressing the function button,
the last registered signal can be
displayed again.
You can also cancel a signal that
was just activated by pressing this
button.
Special accessories
The following modules (not in-
cluded) can be plugged into
to the AUX output connector:
- Vibrating pillow
- Flash module MF-1
- Switch module MS-1* (A-3330-0)
- Acoustic module MA-1 (A-3340-0)
*Only for use with Type C (CEE 7/16 Eu-
roplug) and Type F (CEE 7/4 „Schuko")
outlet connectors
Transmission range
The signal range of the »signolux«
(green)
transmitters can be up to 200
metres under ideal conditions.
(orange)
The following conditions may
(yellow)
result in a reduced range:
-Buildings or vegetation.
(white)
-Interference from TVs, compu-
(red)
(red)
-Positioning of the transmitter at
-Metallic objects reduce the range
-Particularly in towns and cities,
(A-3303-0)
(A-3320-0)
-Having units operating at similar
ter monitors and mobile phones.
Under certain circumstances,
this may prevent the receiver
from functioning at all.
an unfavourable distance from
surfaces which reflect radio
waves, for example floors and
walls. This may lead to the si-
gnal wave being weakened or
even cancelled out by the re-
flected wave.
due to the shielding effect of the
metal.
there may be many other sources
of radio waves which can dis-
rupt the original signal.
frequencies located close to
one another may also result in
mutual interference.
