Wiring Diagram - Zephyr Roma Groove ZRG-E30BS Guide D'utilisation, D'entretien Et D'installation

ZEPHYRONLINE.COM
ZRG Wiring Diagram
WHITE
BLACK
P/C Power Supply
Speaker
Bluetooth Controller
REMARKS: CONDENSER 12.5 + 12.5uF
Roma Groove Use, Care, and Installation Guide
Volts
120
MOTOR
WHITE
BLACK
BODY
LED
LED
250VAC FIT AC120V 60Hz

Wiring Diagram

Hz
Max Amps
60 4
BODY
GREEN
YELLOW
BLUE
BROWN
GREY
WHITE
YELLOW
YELLOW
Controller
RED RED
YELLOW
