ZSL-E42CS, ZSL-E48CS

Wiring Diagram

Body
REMARKS: CONDENSER 11+11uF 250VAC *2 FIT AC120V 60Hz
Power consumption shown for default 1200 CFM blower configuration
ACT 590 CFM - Fan Max. 556W @ 4.6A
ACT 390 CFM - Fan Max. 381W @ 3.4A
Siena Pro Island Use, Care, and Installation Guide
White
Grey
Brown
Blue
Yellow
Red
Green
Body
Motor
Wiring Diagram
Volts Hz
120 60
White
Grey
Brown
Blue
Yellow
Red
Green
Body
Max Amps
7
Motor
25
