CODE (Hex) D es crip t ion
PARAMETER CODES
0048 -P2 • Phase 2 exported active power DMD
DMD
0049 +P3 • Phase 3 imported active power DMD
DMD
004A -P3 • Phase 3 exported active power DMD
DMD
004B +P∑ • System imported active power DMD
DMD
004C -P∑ • System exported active power DMD
DMD
0057 +Q1 • Phase 1 imported reactive power DMD
DMD
0058 -Q1 • Phase 1 exported reactive power DMD
DMD
0059 +Q2 • Phase 2 imported reactive power DMD
DMD
005A -Q2 • Phase 2 exported reactive power DMD
DMD
005B +Q3 • Phase 3 imported reactive power DMD
DMD
005C -Q3 • Phase 3 exported reactive power DMD
DMD
005D +Q∑ • System imported reactive power DMD
DMD
005E -Q∑ • System exported reactive power DMD
DMD
00D7 +kWh1 • Phase 1 imported active energy
00D8 -kWh1 • Phase 1 exported active energy
00D9 +kWh2 • Phase 2 imported active energy
00DA -kWh2 • Phase 2 exported active energy
00DB +kWh3 • Phase 3 imported active energy
00DC -kWh3 • Phase 3 exported active energy
00DD +kWh∑ • System imported active energy
00DE -kWh∑ • System exported active energy
00E0 +kVAh1-C • Phase 1 imported capacitive apparent energy
00E1 -kVAh1-C • Phase 1 exported capacitive apparent energy
00E2 +kVAh1-L • Phase 1 imported inductive apparent energy
00E3 -kVAh1-L • Phase 1 exported inductive apparent energy
00E6 +kVAh2-C • Phase 2 imported capacitive apparent energy
00E7 -kVAh2-C • Phase 2 exported capacitive apparent energy
00E8 +kVAh2-L • Phase 2 imported inductive apparent energy
00E9 -kVAh2-L • Phase 2 exported inductive apparent energy
00EA +kVAh2 • Phase 2 imported apparent energy
00EB -kVAh2 • Phase 2 exported apparent energy
00EC +kVAh3-C • Phase 3 imported capacitive apparent energy
00ED -kVAh3-C • Phase 3 exported capacitive apparent energy
00EE +kVAh3-L • Phase 3 imported inductive apparent energy
00EF -kVAh3-L • Phase 3 exported inductive apparent energy
00F2 +kVAh∑-C • System imported capacitive apparent energy
00F3 -kVAh∑-C • System exported capacitive apparent energy
00F4 +kVAh∑-L • System imported inductive apparent energy
00F5 -kVAh∑-L • System exported inductive apparent energy
00FB +kvarh1-C • Phase 1 imported capacitive reactive energy
00FC -kvarh1-C • Phase 1 exported capacitive reactive energy
00FD +kvarh1-L • Phase 1 imported inductive reactive energy
00FE -kvarh1-L • Phase 1 exported inductive reactive energy
00FF +kvarh2-C • Phase 2 imported capacitive reactive energy
0100 -kvarh2-C • Phase 2 exported capacitive reactive energy
0101 +kvarh2-L • Phase 2 imported inductive reactive energy
0102 -kvarh2-L • Phase 2 exported inductive reactive energy
0103 +kvarh3-C • Phase 3 imported capacitive reactive energy
0104 -kvarh3-C • Phase 3 exported capacitive reactive energy
