Technical Data; Equipment Function; Description; Basic Unit (Fig. A) - Virax P160 B PRO BASIC Manuel D'utilisation

20 Check the electric tool for damage. Before using the electric tool, you must inspect safety
equipment or slightly damaged parts carefully to ensure that they work properly and as intended.
Check to see that the moving parts operate freely and don't stick, and to make sure no parts are
damaged. All parts must be mounted properly and meet all the conditions for ensuring trouble-
free operation of the electric tool. Damaged safety equipment and parts must be properly
repaired or replaced by a professional facility, unless otherwise indicated in the user manual.
Damaged switches must be replaced by a customer service facility. Never use an electric tool
whose switch cannot be turned on and off.
21 Caution. Using other insertion tools and accessories may cause injury.
22 Have your tool repaired by an electrical expert. This electric tool meets applicable safety
requirements. Repairs must be made only by an electrical expert using original replacement
parts. Otherwise accidents many occur.

2. Technical data

See document "Technical data"

3. Equipment function

3.1. Description

The VULCA PRO BASIC VIRAX are compact, transportable heating element butt fusion
welding machines that were specially designed for use at the construction sites and in
particular in pipe trenches. Of course, the tools are very well suited for use in the workshop.
The versatility of the VULCA machines allows the operator to securely join 40 – 630 mm
(outer dimensions) PE - PP and PVDF pipes for all plumbing and sanitation applications as
listed below:
I. pipe
II. pipe
III. pipe
IV. pipe
The essential machine components are basic unit, reduction clamp insets, hydraulic unit, trimmer
unit, heating plate, carrying frame.
When joining welding necks always use the flange adapter (optional accessory, must be
ordered separately).

3.1.1. basic unit (fig. A)

1
2
3
4
- pipe
- pipe bends
- T-joints
- welding neck
Movable clamps
Sliding clamps
Spacer with locking notch
Heating element take-off device
22
