Endress+Hauser Proline Promag E Instructions Condensées page 27

Proline Promag E
Diamètre nominal
[mm]
40
40
50
50
65
65
80
80
100
100
125
125
150
150
200
200
250
250
300
300
JIS B2220, 10/20K
Diamètre nominal
[mm]
350
350
400
400
450
450
500
500
Endress+Hauser
Palier de pression
[bar]
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
10K
20K
Palier de pression
[bar]
10K
20K
10K
20K
10K
20K
10K
20K
Vis Couple de serrage max. des vis [Nm]
[mm]
4 × M16
4 × M16
4 × M16
8 × M16
4 × M16
8 × M16
8 × M16
8 × M20
8 × M16
8 × M20
8 × M20
8 × M22
8 × M20
12 × M22
12 × M20
12 × M22
12 × M22
12 × M24
16 × M22
16 × M24
Vis Couple de serrage norm. des vis [Nm]
[mm]
16 × M22
16 × M30×3
16 × M24
16 × M30×3
16 × M24
16 × M30×3
16 × M24
16 × M30×3
PTFE
41
41
54
27
74
37
38
57
47
75
80
121
99
108
82
121
133
212
99
183
PUR
109
217
163
258
155
272
183
315
Annexe
PFA
37
37
46
23
63
31
32
46
38
58
66
103
81
72
54
88
–
–
–
–
HG
109
217
163
258
155
272
183
315
27
