Technical data

Portable circular saw
Power
No-load speed
1
Max. speed
Inclination
Cutting depth at 0°
Cuttung depth at 45°
Saw blade dimensions
Weight (without mains
cable)
Safety class
1.
Max. possible speed with faulty electronics.
Plunge-cut saws are intended to be used for sawing
wood, materials similar to wood, plaster and ce-
ment-bonded fibre materials and plastics. When
fitted with special saw blades for aluminium of-
fered by Festool, these machines can also be used
for sawing aluminium.
Only saw blades with the following specifications
may be used: Saw blade diameter 160 mm, cutting
width 2,2 mm, location hole 20 mm, max. standard
blade thickness 1,8 mm, suitable for speeds up to
10
All manuals and user guides at all-guides.com
The pictures for the functional description are on a
TS 55 REQ
fold-out page at the beginning of the instruction
1200 W
manual. When reading of the manual you can fold
out this page for having always an overview of the
2000 - 5200 rpm
machine.
7300 rpm
-1° to 47° [1-1] Adjustable jaws
0 - 55 mm [1-2] Angle scale
(0 - 2.17 in.) [1-3] Rotary knobs for angle adjustment
0 - 43 mm [1-4] Handles
(0 - 1.62 in.) [1-5] Lever for changing blades
[1-6] Switch-on lock
160x2.2x20 mm
[1-7] On/Off switch
(6.3x0.09x0.79 in.)
[1-8] Extractor connector
4.5 kg (9.92 lb.)
[1-9] Release button for undercuts between -1°
/II
[1-10]Speed control
[1-11]Mains power cable
[1-12]Split scale for cutting depth stop (with/with-
[1-13]Cutting depth adjusting screw for resharp-
[1-14]Cutting depth stop
[1-15]Cut indicator
[1-16]Viewing window / chipguard
[1-17]Splinterguard

Intended use

9500 rpm. Never use abrasive wheels in the ma-
chine.
The machine is designed and approved for use by
trained persons or specialists only.
– Festool electric power tools must only be in-

Functional description

and 47°
out guide rail)
ened saw blades
stalled on work tables provided by Festool for
this purpose. If the tool is installed in another, or
self-made, work table, it can become unstable
and result in serious accidents.
The user is liable for improper or non-in-
tended use.
