dji PHANTOM 4 RTK Guide De Démarrage Rapide page 9

Weight (Battery & Propellers Included)
Max Service Ceiling Above Sea Level
Max Ascent Speed
Max Descent Speed
Max Speed
Max Flight Time
Operating Temperature
Operating Frequency
EIRP
Hover Accuracy Range
Single-Frequency High-Sensitivity
GNSS
Multi-Frequency Multi-System High-
Precision RTK GNSS
Mapping Accuracy**
Ground Sample Distance (GSD)
Controllable Range
Velocity Range
Altitude Range
Operating Range
Obstacle Sensory Range
Operating Environment
Obstacle Sensory Range
Operating Environment
Sensor
Lens
ISO Range
* supported later
** The actual accuracy depends on surrounding lighting and patterns, aircraft altitude, mapping software used, and other factors when
shooting.
8
All manuals and user guides at all-guides.com
1391 g
19685 ft (6000 m)
3 m/s
Approx. 30 minutes
32° to 104° F (0° to 40° C)
2.400 GHz to 2.483 GHz (Europe, Japan, Korea)
5.725 GHz to 5.850 GHz (United States, China)
2.4 GHz
CE (Europe) / MIC (Japan) / KCC (Korea): < 20 dBm
5.8 GHz
FCC (United States) / SRRC (Mainland China) / NCC (Taiwan, China): < 26 dBm
RTK enabled and functioning properly:
RTK disabled:
The position of the camera center is relative to the phase center of the onboard D-RTK
antenna under the aircraft body's axis: (36, 0, and 192 mm) already applied to the image
coordinates in Exif data. The positive x, y, and z axes of the aircraft body point to the
forward, rightward, and downward of the aircraft, respectively.
Frequency Used
First-Fixed Time: < 50 s
1 ppm indicates error with a 1 mm increase over 1 km of movement.
Velocity Accuracy: 0.03 m/s
Mapping accuracy meets the requirements of the ASPRS Accuracy Standards for Digital
Orthophotos Class III.
(H/36.5) cm/pixel, H indicates the aircraft altitude relative to the shooting scene (unit: m)
Max operating area of approx. 1 km
approx. 5 cm/pixel, meeting the requirements of the ASPRS Accuracy Standards for Digital
Orthophotos Class III).
Pitch: -90° to +30°
0 - 33 ft (0 - 10 m)
0 - 33 ft (0 - 10 m)
2 - 98 ft (0.7 - 30 m)
Surfaces with clear patterns and adequate lighting (> 15 lux)
0.6 - 23 ft (0.2 - 7 m)
FOV (Field of View) 84°, 8.8 mm (35 mm format equivalent: 24 mm), f/2.8 - f/11, auto focus
Video: 100 - 3200 (Auto),
2
, 100 - 12800 (Manual)
