The Phantom 4 RTK remote controller has a transmission range of up to 4.3 mi (7 km) * with controls for
camera tilt and photo capture. DJI OcuSync is built into the remote controller, transmitting live HD imaging
an operation for convenient project management. Users can also connect the remote controller to a PC to
access DJI PC GS Pro for planning and executing operations. The remote controller's Multi-Aircraft Control
quick maintenance.
14
16
17 18
The figure below shows the function that each control stick movement performs, using Mode 2 as an
example. The left stick controls the aircraft's altitude and heading, while the right stick controls its forward,
backward, left and right movements. The gimbal dial controls the camera's tilt.
