PREPARATION

Before beginning assembly of product, make sure
all parts are present. Compare parts with package
contents list and hardware contents list. If any part is
missing or damaged, do not attempt to assemble the
product.

ASSEMBLY INSTRUCTIONS

1. From behind the assembly, align the holes on
left front panel (E) with the corresponding holes
on left wall (C). securing with two washers (BB)
and two long bolts (AA).
Repeat for right wall (D)
Hardware Used
Long Bolt
AA
Washer
BB
2. Insert four wooden dowels (CC) into holes on left
outer side of base (J). Place assembly from Step
1 onto base (J), securing with three washers
(BB) and three long bolts (AA).
Repeat for right wall (D).
Hardware Used
Long Bolt
AA
Washer
BB
Wooden Dowel
CC
Estimated Assembly Time: 50 minutes
Tools Required for Assembly (not
included): Phillips screwdriver
