CORNER ASSEMBLY (CONT'D)
2. Insert four wooden dowels (CC) into the top
back holes of mantel, Attach corner panel (B),
secure with five washers (BB) and five long bolts
(AA).
Assembly is now complete. With the help of
another person, move the assembly to the final
desired location. Once in final position you may
plug the heater into the power outlet.
Hardware Used
Long Bolt
AA
Washer
BB
Wooden Dowel
CC
NOTE: Use the pre-assembled levelers on the
base of the fireplace to level the unit. Twist the
levelers counterclockwise to increase the height,
twist the clockwise to decrease the height.

CHANGE DOOR PANEL (OPTIONAL)

Note: The pre-installed glass door panel can be switched out with the included wood door panel (H).
1. Remove the silicone trim along the outer edges of the glass panel on the inside of the flip down
door. Start at a corner and pull to remove the four pieces. Be careful not to damage the silicone
trim as it will be used to secure the new panel.
2. Remove the glass panel from the door frame, then insert the included wood door panel (H).
3. Using your finger press the silicone trim back into place. Move around the outer edge of the panel
until all four sides are secure.
