ASSEMBLY INSTRUCTIONS (CONT'D)
9. Insert the fireplace brick wall (K) into the mantel,
slotting it into the grooves on base (J). Secure
it by using two screws (EE) into the L-bracket
(FF).
Hardware Used
Screw
EE
10. Place this panel on top of firebox with corner
bumpers facing inward.

CORNER ASSEMBLY (OPTIONAL)

1. From behind the assembly, Attach L corner
support rod (I), secure with one washer (BB) and
one long bolt (AA).
Hardware Used
Long Bolt
AA
Washer
BB
9
x 2
EE
J
10
1
x 1
x 1
11
1
K
I
BB
AA
