Nice MhouseKit CL2SL Instructions Et Avertissements Pour L'installation Et L'utilisation page 30

cascade
Connection
A - Electricity supply line
B - FLASH flasher output
C - Radio antenna
D - ECSbus Input/Output
E - STOP input
F - OPEN input
G - Motors M1 and M2 output
Note 1 - You may use a cable longer than 30 m, provided it has a larger gauge (for example, 3 x 2.5 mm
automation, safety grounding.
Note 2 - For the ECSbus cables and the STOP and OPEN input cables, you can also use a single cable with more internal conductors, to group
multiple connections: for example, the STOP and OPEN inputs can be connected to the KS100 selector switch with a cable of 4 x 0.5 mm
WARNING! – The cables used must be suited to the installation environment.; for example a cable type H03VV-F is recommended
for indoor environments, and a cable type H07RN-F for outdoor environments is recommended.
a
1
e
A
2
4 – English
star combined
TABLE 2 – Technical specifications of electric cables
Cable type (minimum gauge values)
Cable 3 x 1.5 mm
2
Cable 2 x 0.5 mm
2
RG58 type of protected cable
Cable 2 x 0.5 mm
2
Cable 2 x 0.5 mm
2
Cable 2 x 0.5 mm
2
Cable 3 x 1 mm
2
b c
g
f
B C D
D G
Max allowable length
30 m (note 1)
20 m
20m (recommended less than 5m)
20 m (note 2)
20 m (note 2)
20 m (note 2)
10 m
c
g
h
D
G
) and it is equipped with, close to the
2
2
d
f
e
E F
.
