Instructions for installation and use

2.2. Wall element installation

The corner posts are connected to the wall elements using Multiclips. The other
wall elements are connected by tongue and groove and are screwed together.
A always refers to the visible side. This is labelled on the top side of the
wall elements.
Attention!
The installation subsequently described is for the right floor plan.
For changes affecting installation for the left floor plan see Page 32.
*
*
*
*
Multiclips
Right floor plan
*
p. 9/32
EN
*
*
*
*
