Package Include
Product Qty
Walkie talkie 1
lithium battery 7.4V 1
Charger 1

Familiar with walkie-talkie

Antenna
Indicator
PTT button
PF1 definition key/
Channel increment
PF2 defines key/
Channel decrement
Product
Belt clip
Manual
Lanyard
volume/power switch
Flashlight
Speaker
Microphone
Programming cable /
External headset port
01

Charging instructions

Charging mode: Insert the walkie-talkie into the charger's
Qty
charging slot. At this time, the charger is
on. The red light indicates that charging is
1
started, and the green light indicates that
1
the battery is fully charged. (as the picture
1
shows)

Basic operation and function description

Power on/off:
Turn the volume switch potentiometer clockwise to hear a
"click" to indicate that the power is on, counterclockwise
rotate the volume switch potentiometer and hear a "click" to
indicate that the power is off.
Talking:
Press and hold the PTT button to launch, the indicator light turns red, and speak at the microphone
hole, at this time, the other party will hear your own speaking information. After speaking, release
the PTT button, to receive the other party's speaking information. The green indicator lights up at
the same time when the other party's information is reached.
Volume up/down:
Turn the volume switch potentiometer clockwise to increase the volume, and turn the volume switch
potentiometer counterclockwise to decrease the volume.
Channel adjustment:
Press the PF1/channel increase button to increase the channel in sequence, and press the
PF2/channel decrease button to decrease the channel in sequence.
Low battery voltage reminder:
When the walkie-talkie reports the voice prompt "please charge" and the indicator flashes red, it
means that the battery voltage is lower than the working voltage. Please charge the walkie-talkie.
VOX:
Press and hold the PF1/PF2 side key function definition button with VOX for 2 seconds to turn on
VOX function, and repeat the operation to adjust the VOX level. The higher the level, the lower the
voice when activating VOX. Turn off the VOX function by hearing a beep.
Monitor:
Press and hold the definition key set with monitor function for 2 seconds to turn on the monitor
function, release the button to turn off the monitor function.
Flashlight:
Press and hold the definition key set with the flashlight function for 2 seconds to turn on the
flashlight function, repeat the operation to turn off the flashlight.
Alarm:
Press and hold the definition key with the alarm function set for 2 seconds to turn on the alarm
function, press the PTT button to cancel the alarm.Press the PF1/chann.
Channel lock:
Press and hold the definition key set with the channel lock function for 2 seconds, the radio will emit
a beep to indicate that the channel lock function is enabled, and the channel adjustment cannot be
performed at this time. Repeat the operation to turn off the channel lock Features.
charging indicator
02
