Hama WLAN Router 300 Notice D'utilisation page 70

g
Operation as AP bridge point to point
Channel number
Mac address 1
Security settings
‹ In the next mask, click the button "Apply" and in the following
mask also "Apply" to operate a wireless LAN without encryption.
The device is then restarted. After the restart, the wireless LAN is
immediately available.
70
Configuration and operation
Input field Comments
Define whether the device operates in
the 2.4 Ghz band to standard 802.11b (11
Band
Mbps), 802.11g (54 Mbps) or combined with
802.11b and 802.11g.
Select here the channel via which the data
are to be transmitted. 13 channels are avail-
able.
Enter here the address of the access point
to which the Bridge connection is to be
made.
Click this button to set the encryption for
your wireless LAN.
The instructions for setting the wireless LAN
encryption can be found in chapter Set-
ting of the encryption for bridge point
to point, bridge point to multi-point and
bridge WDS .
WLAN Router 300
