Hama WLAN Router 300 Notice D'utilisation page 69

Configuration and operation
Operation as access point (AP)
Channel number
Associated clients
‹ Click the button "Apply" to save the settings.
To set the encryption for your wireless LAN:
‹ In the next mask, click the button "Continue".
‹ Select "Security settings" in the menu on the left.
The instructions for setting the wireless LAN encryption can be found
in chapter Setting of the AP encryption .
‹ In the next mask, click the button "Apply" to operate a wireless
LAN without encryption.
The device is then restarted. After the restart, the wireless LAN is
immediately available.
WLAN Router 300
Input field Comments
Define whether the device operates in
the 2.4 Ghz band to standard 802.11b (11
Band
Mbps), 802.11g (54 Mbps) or combined with
802.11b and 802.11g.
Enter the name of the wireless LAN here.
The length of the SSID can be up to 32 char-
acters and must be identical for all devices
SSID
in the network.
Example: "WLAN_Router_54Mbps"
Select here the channel via which the data
are to be transmitted. 13 channels are avail-
able.
Activate the checkbox "Show active clients"
to display all client computers logged in to
your access point.
g
69
