Description

Rear side of the device

2
3
4
5
6
52
3
2
Connections for WLAN antennae:
For connection of the WLAN antennae contained in the scope
of supply. They allows devices such as PCs, notebooks or
PDAs to make wireless contact with the device.
Radio ON/OFF:
For switching off the WLAN function (e.g. over night). Cable-
bound LAN interfaces are not affected.
Reset/WPS:
The Reset/WPS button has two functions:
■ Holding the button depressed (10 seconds) resets the
device to the works default settings.
■ Pressing briefly allows devices to be added to an existing
network.
LAN jacks 1-4:
For connection of devices such as PC or notebook via LAN
cable.
WAN port:
For connection to a broadband modem or other router.
12 VDC jack:
For connection of the mains adapter.
4 5 6
