MIDI MAP
SW name Type MIDI
SW/ENC 2B/32
VR/CENTER 32/2C
CW/CCW 32/33
JOG
SW/ENC 20/35
JOG CW/CCW 35/36
JOG X SW/ENC 20/37
JOG X CW/CCW 37/38
JOG Y SW/ENC 20/39
JOG Y CW/CCW 39/3A
Pitch Silder VR/CENTER PITCHBEND/26
<< SEARCH >> VR
BANK P. SW
SGL/CTN SW
Time SW
>>| SW
|<< SW
SHIFT SW
EJECT SW
RELOOP SW
BPM SW
TAP SW
SW
SW
% SW
CUE SW/LED 07/07
SW/LED 01/01
1/8 SW/LED 05/05
1/4 SW/LED 06/06
1/2
SW/LED 2A/2A
3/4 SW/LED 24/24
1/1 SW/LED 1E/1E
2/1
SW/LED 0C/0C
4/1 SW/LED 12/12
SCRATCH SW/LED 2F/2F
SKID
SW/LED 29/29
FILTER SW/LED 11/11
PHASE SW/LED 0B/0B
HOLD SW/LED 1D/1D
ECHO SW/LED 23/23
FLANGER SW/LED 21/21
TRANS SW/LED 27/27
PAN SW/LED 2D/2D
LOOP IN SW/LED 16/16
LOOP OUT SW/LED 2E/2E
1
SW/LED 1C/1C
2 SW/LED 0A/0A
3 SW/LED 10/10
4
SW/LED 0F/0F
SAVE TO SW/LED 04/04
SAMPLER SW/LED 28/28
SW/LED 14/14
PITCH SW/LED 0E/0E
SCRATCH(2) LED
1(2) LED
2(2) LED
3(2) LED
4(2) LED
100 LED
16 LED
8 LED
4 LED
PITCH 0 LED
REVERSE LED
MIDI MAP
MIDI2(Hold shift) Remarks
CC TYPE =
6A/71
RELATIVE
CC TYPE =
71/6B
ABSOLUTE
71/72 CC TYPE = NOTE
CC TYPE =
5F/74(VR)
RELATIVE
- - CC TYPE = NOTE
CC TYPE =
5F/76(VR)
RELATIVE
- - CC TYPE = NOTE
CC TYPE =
5F/78 (VR)
RELATIVE
- - CC TYPE = NOTE
31/65
15 54
25 64
1F 5E
19 58
0D 4C
13 52
42
1B 5A
22 61
09 48
03 42
08 47
02 41
1A 59
46/07
40/01
44/05
45/06
69/2A
63/24
5D/1E
4B/0C
51/12
6E/2F
68/29
50/11
4A/0B
5C/1D
62/23
60/21
66/27
6C/2D
55/16
6D2E
5B/1C
49/0A
4F/10
4E/0F
43/04
67/28
53/14
4D/0E
31
32
33
34
35
36
37
38
39
3A
30
CC-ABSOLUTE (VR)
Control Change messages are sent with
status 0xBn, where n is the channel, for
the specified CC controller. Thus the cont-
roller MIDI ID is indicated with the channel
along with the CC number. The value from
0x00 to 0x7F, directly related to the loca-
tion of the controller.
CC-RELATIVE (ENC)
Control Change messages are status 0xBn,
where n is the channel, for the specified CC
controller. Thus the controller MIDI ID is in-
dicated with the channel along with the CC
number. The value from 0x40 to indicate
the change in the controller. This is an off-
set to 0x40 "one's complement" notation.
A message with data 0x43 indicates a po-
sitive change of 3. A messages with data
0x31 indicates a negative change of 15.
SWITCH ON/OFF (SW,CENTER,CW,CCW)
These messages are used for switches.
Control Change messages are sent with
status 0x9n, SWITCH On and Off value are
0x7F and 0x00, where n is the channel.
LED ON/OFF (LED)
These messages are used for LED. Control
Change messages are sent with status
0x9n, LED On and Off value are 0x7F and
0x00, where n is the channel.
