ViewSonic PX701-4K Guide De Démarrage Rapide

PX701-4K
Home Projector
Quick Start Guide Przewodnik Szybki start
Guia de Início Rápido
快速安装说明
快速入門指南 Ghid de pornire rapidă
빠른 시작 가이드 краткое руководство по
クイックスタートガイド
началу работы
Ръководство за бърз старт Vodič za brzi početak
Vodič za brzo pokretanje Príručka so stručným návodom
Úvodní příručka Vodnik za hitri začetek
Aan de slag Guía de inicio rápido
Pika-aloitusopas Snabbstartsguide
Guide de démarrage rapide Hızlı Başlangıç Kılavuzu
Schnellstarthandbuch короткий посібник користувача
Οδηγός γρήγορης εκκίνησης Panduan Mulai Cepat
Első lépések ‫دﻟﯾل اﻟﺑدء اﻟﺳرﯾﻊ‬
Guida introduttiva
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
4
On Off
COMP HDMI 1 HDMI 2
Auto
Source
Sync
MENU
BLANK
EXIT
COLOR
SOURCE MODE
Aspect Freeze Pattern Blank
PgUp
PgDn
Color
Network
Mode
1
PX701-4K
Home Projector
Quick Start Guide Przewodnik Szybki start
快速安装说明 Guia de Início Rápido
快速入門指南 Ghid de pornire rapidă
빠른 시작 가이드 краткое руководство по
クイックスタートガイド
началу работы
Ръководство за бърз старт Vodič za brzi početak
Vodič za brzo pokretanje Príručka so stručným návodom
Úvodní příručka Vodnik za hitri začetek
Aan de slag Guía de inicio rápido
Pika-aloitusopas Snabbstartsguide
Guide de démarrage rapide Hızlı Başlangıç Kılavuzu
Schnellstarthandbuch короткий посібник користувача
Οδηγός γρήγορης εκκίνησης Panduan Mulai Cepat
Első lépések ‫دﻟﯾل اﻟﺑدء اﻟﺳرﯾﻊ‬
Guida introduttiva
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
5
Screws: M4 x 8 (Max. L = 8 mm)
Unit: mm
222 mm
MENU BLANK
EXIT
COLOR
SOURCE MODE
312 mm
108 mm
2
1
2
MENU BLANK
EXIT
SOURCE COLOR
MODE
On
4
3
COMP HDMI 1
Auto
Sync
MENU
BLANK
EXIT
COLOR
SOURCE MODE
Aspect Freeze Pattern
• 16:9 image on a 16:9 screen
PgUp
PgDn
Color
Network
Mode
• 16:9 image on a 4:3 screen
3
HDMI 1 HDMI 2
HDCP2.2 HDCP2.2
Off
HDMI 2
Source
16:9 image on a 16:9 Screen
Blank
(a) Screen Size (b) Projection distance
(c) Image
m i . n m a . x height
inch mm inch mm inch mm inch mm
60 1524 78.6 1995.8
86.4 2195.4 29.4 747.2
70 1778 91.7 2328.4 100.8 2561.3 34.3
871.7
80 2032 104.8 2661.1 115.2 2927.2 39.2 996.2
90 2286 117.9 2993.7 129.6 3293.1 44.1 1120.7
100 2540 131.0 3326.3 144.1 3658.9 49.0 1245.3
110 2794 144.1 3658.9 158.5 4024.8 53.9 1369.8
120 3048 157.1 3991.6 172.9 4390.7 58.8 1494.3
130 3302 170.2 4324.2 187.3 4756.6 63.7 1618.8
140 3556 183.3 4656.8 201.7 5122.5 68.6 1743.4
150 3810 196.4 4989.5 216.1 5488.4 73.5 1867.9
160 4064 209.5 5322.1 230.5 5854.3 78.4 1992.4
170 4318 222.6 5654.7 244.9 6220.2 83.3 2116.9
180 4572 235.7 5987.4 259.3 6586.1 88.2 2241.5
190 4826 248.8 6320.0 273.7 6952.0 93.1 2366.0
200 5080 261.9 6652.6 288.1 7317.9 98.1 2490.5
16:9 image on a 4:3 Screen
(a) Screen Size (b) Projection distance
(c) Image
height
m i . n m a . x
inch mm inch mm inch mm inch mm
60 1524 72 1831.9 79 2015.1 27.0 685.8
70 1778 84 2137.2 93 2350.9 31.5 800.1
80 2032 96 2442.5 106 2686.8 36.0 914.4
90 2286 108 2747.8 119 3022.6 40.5 1028.7
100 2540 120 3053.2 132 3358.5 45.0 1143.0
110 2794 132 3358.5 145 3694.3 49.5 1257.3
120 3048 144 3663.8 159 4030.2 54.0 1371.6
130 3302 156 3969.1 172 4366.0 58.5 1485.9
140 3556 168 4274.4 185 4701.9 63.0 1600.2
150 3810 180 4579.7 198 5037.7 67.5 1714.5
160 4064 192 4885.0 212 5373.5 72.0 1828.8
170 4318 204 5190.4 225 5709.4 76.5 1943.1
180 4572 216 5495.7 238 6045.2 81.0 2057.4
190 4826 228
5801.0 251 6381.1 85.5 2171.7
200 5080 240 6106.3 264 6716.9
90.0 2286.0
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should
physically test the projection size and distance using the actual projector in situ before
you permanently install it, so as to make allowance for this projector's optical
characteristics. This will help you determine the exact mounting position so that it best
suits your installation location.
USB 5V/1.5A OUT
RS-232 AUDIO OUT (Service)
(d) Vertical offset
m i . n m a . x
inch mm inch mm
2.9 74.7 2.9 74.7
3.4 87.2 3.4 87.2
3.9 99.6
3.9 99.6
4.4 112.1 4.4 112.1
4.9 124.5 4.9 124.5
5.4 137.0 5.4 137.0
5.9 149.4 5.9 149.4
6.4 161.9 6.4 161.9
6.9 174.3 6.9 174.3
7.4 186.8 7.4 186.8
7.8 199.2 7.8 199.2
8.3 211.7 8.3 211.7
8.8 224.1 8.8 224.1
9.3 236.6 9.3 236.6
9.8 249.1 9.8 249.1
(d) Vertical offset
m i . n m a . x
inch mm inch mm
2.7 68.6 2.7 68.6
3.2 80.0 3.2 80.0
3.6 91.4 3.6 91.4
4.1 102.9 4.1 102.9
4.5 114.3 4.5 114.3
5.0 125.7 5.0 125.7
5.4 137.2 5.4 137.2
5.9 148.6 5.9 148.6
6.3 160.0 6.3 160.0
6.8 171.5 6.8 171.5
7.2 182.9 7.2 182.9
7.7 194.3 7.7 194.3
8.1 205.7 8.1 205.7
8.6 217.2 8.6 217.2
9.0 228.6 9.0 228.6
