Components and functions
Installing the optional BN-R5000 battery
A rechargeable battery is available for the RV-NB200BT and RV-NB300DAB. To install the battery in,
please proceed as follows:
Attention: Use only the battery pack BN-R5000! Risk of explosion if the battery is replaced by
an incorrect type.
• Remove the battery compartment cover locking screw (indicated by arrow marking
with a suitable Phillips screwdriver.
• Press down the left and right latches of the lid and remove them.
• The battery should be positioned so that the connection cable is pointing to the left and the
screwed bottom is down.
• Connect the connecting cables and carefully insert the battery into the battery compartment. The
connection cable is stowed on the left side of the compartment. Avoid crushing the cables.
• Put the lid back into the battery compartment and snap the two tabs into the compartment.
Then insert the screw and tighten.
The battery is being charged in the device. You can read the charge status in the display as a symbol
display.
Please note: In battery mode, this device can not be turned on with remote control. This is to extend
the lifetime of the battery.
If you dispose of the product, please remove the battery pack for separate disposal.
10
5
, see page 8)
