TX207
Technical Data/Certification Data
Power Supply
Supply voltage
Current consumption
General Information
Operating temperature
Storage temperature
Relative humidity
Protection class
© Hans Turck GmbH & Co. KG | 100002509 2018-05 DE EN FR
24 V DC (10 to 32 V DC)
0.3 A at 24 V DC (max.)
0°C...50 °C (vertical installation)
-20 °C...+70 °C
5...85 % RH, non condensing
IP66 (front), IP20 (rear)
For use in pollution degree 2 environment
