turck TX-EXTEND Mode D'emploi Simplifié

TX-EXTEND


Technical Data
Device
Type
Ident no.
Power supply
The plug-in module is supplied via the backplane bus connector from the HMI
(TX500, TX700).
Environmental Conditions
Operating temperature
Storage temperature
Operating and storage humidity
Protection class
Approvals
UL
DNV-GL
© Hans Turck GmbH & Co. KG | 100005949 2019-06 DE EN FR
TX-EXTEND
100004786
-20°...+60°C
-20°...+70°C
5...85 % relative humidity, non-condensing
IP20
For installation in industrial environments:
- emission EN 61000-6-4,
- immunity EN 61000-6-2,
For marine environments:
- emission/immunity EN 60945
cULus (UL File No. E484727)
Class 1 Div. 2 (UL File no. E484803)
Yes
