Installing a front mount reflector on the handlebar
1. Loosen and remove the bracket screw (2) from the plastic bracket (4).
2. Install the plastic bracket loop (4) onto the handlebar tube.
3. Position the plastic bracket (4) on the handlebar (3) between the grip and the crossbar, about 12.7 cm
from the end of the handlebar.
4. Tighten the bracket screw (2) securely. If the bracket is still loose, insert a shim inside to make it tight.
4
3
1
2
1. Reflector
2. Clamp screw
3. Handlebar
4. Reflector bracket
CAUTION: Ensure that the reflector is
vertical to the ground and facing straight
forward. If the reflector is aimed up or
down, incoming headlights may not
reflect properly on the reflector.
