Assembly

Fitting the ceramic hob
A hob should preferably not be positioned
immediately above a refrigerator or freezer
built-in below the worktop. If the hob has to be
fitted above a refrigerator or freezer, ensure
that the hob is well insulated.
25
min. 5
Avoid direct contact with the bottom side of
the hot plate. Put a wooden plate of at least
5 mm thickness at 25 mm from the bottom side
of the hot plate to prevent discolouring/
deformation of the underlying panels/objects.
511
580
51
560 490
Please note:
Do not fit a hob next to a cupboard or wall
made of flammable material above the
worktop. (If there is no alternative then keep
to a minimum distance of 40 mm between the
outer edge of the hob and this wall. Keep a
distance of at least 650 mm between the hob
and any extractor hood to be fitted.)
Mark out the cut out (560 x 490 mm) on the
worktop (see fig. 6).
Stick the sealing strip (A) supplied onto the
underside of the hob (see fig. 7 and 8).
fig. 5
A
right
wrong
A
A
fig. 6
Place the hob in the cut out.
For CKB 640 only: secure the fixing
brackets (see fig. 9).
After fitting the hob check that the
appliance operates correctly.
fig. 7 CKB 640
fig. 8 CKB 660
Disposal of packaging and
appliances
The packaging of the appliance is recyclable.
It is made up off:
- cardboard
- polyethylene
- CFC free polystyrene (PS rigid foam)
- polypropylene straps around the box
30 mm
50 mm
Please dispose of these materials in a
fig. 9
responsible way in accordance with the
regulations of your local authority.
Your local authority will also be able to give
you information about disposing disused
household appliances in a responsible way.
