ENGLISH
- Master/Slave (master) [ OFF ]
(UNIPRO ⇒ Advanced logics ⇒ address 11)
ON: The control panel is set as Master in a centralised connection (see
Paragraph 14).
OFF: The control panel is set as Slave in a centralised connection (see
Paragraph 7).
- Gate-open or 2nd radio channel warning light (sca-2ch) [ OFF ]
ON: The output between terminals 18 and 19 is configured as Gate-open
warning light, in this case the 2nd radio channel controls pedestrian
opening.
OFF: The output between terminals 18 and 19 is configured as 2nd radio
channel.
- Fixed code (fixed code) [ OFF ]
(UNIPRO ⇒ Advanced logics ⇒ address 13)
ON: The receiver is configured for operation in fixed-code mode, see pa-
ragraph on "Radio Transmitter Cloning".
OFF: The receiver is configured for operation in rolling-code mode, see
paragraph on "Radio Transmitter Cloning".
- Radio transmitter programming (radio prog) [
(UNIPRO ⇒ Advanced logics ⇒ address 15)
ON: This enables transmitter storage via radio:
1 – First press the hidden key (P1) and then the normal key (T1, T2,
T3 or T4) of a transmitter already memorised in standard mode by
means of the radio menu.
2 – Within 10s press the hidden key (P1) and the normal key (T1, T2,
T3 or T4) of a transmitter to be memorised.
The receiver exits the programming mode after 10s, other new tran-
smitters can be entered before the end of this time.
This mode does not require access to the control panel.
OFF: This disables transmitter storage via radio.
The transmitters can only be memorised using the appropriate Radio
menu.
- Photocell test (test phot) [ OFF ]
(UNIPRO ⇒ Advanced logics ⇒ address 13)
ON: Activates photocell check (see fig. 7 to 14)
OFF: Deactivates photocell check
- Photocell test on closing (test phot cl. ) [ OFF ]
ON: Enables the test of the active photocells on closing.
OFF: Desables the test of the active photocells on closing.
- Electric edge test (test bar) [ OFF ]
- Menu visible with safety edge activated only.
UNIPRO ⇒ Advanced logics ⇒ address 14)
ON: Activates electric edge check (see fig. 7 to 14)
OFF: Deactivates electric edge check
- Photocell test on opening (test phot op. ) [ OFF ]
- Menu visibile with safety edge deactivated only.
ON: Enables the test of the active photocells on opening.
OFF: Desables the test of the active photocells on opening.
9.3) RADIO MENU (RADIO)
- Add (add)
Allows you to add one key of a radio control device to the receiver memory;
after storage it displays a message showing the receiver number in the
memory location (from 01 to 64).
Add Start button (add start)
associates the required key to Start command
Add 2ch button (add 2ch)
associates the required key to 2nd radio channel
- Read (read)
Checks one key of a receiver; if stored it displays a message showing
the receiver number in the memory location (from 01 to 64), and the key
number (T1, T2, T3 or T4).
- Eliminate list (erease 64)
WARNING! Completely removes all memorised radio control devices
from the receiver memory.
- Receiver code reading (RX code)
This displays the code entered in the receiver (par.11).
Consult paragraphs 8/9/10/11 for further information concerning the
advanced functions of the Clonix incorporated receiver.
9.4) Language Menu (Language)
Allows you to set the language on the display programmer.
5 languages are available:
- ITALIAN (TA)
- FRENCH (FRA)
- GERMAN (DEU)
- ENGLISH (ENG)
- SPANISH (ESP)
16 -
RIGEL 5 - Ver. 04
INSTALLATION MANUAL
9.5) MENU DEFAULT (DEFAULT)
Restores the preset default values on the control unit.
9.6) DIAGNOSTICS AND MONITORING
The display on the RIGEL 5 panel shows some useful information, both
during normal operation and in the case of malfunctions.
Diagnostics:
In the case of malfunctions, the display shows a message indicating which
device needs to be checked:
STRE
STRI
PED
OPEN
CLS
STOP
PHOT
PHOP
PHCL
ON ] BAR
SWC1
SWO1
SWC2
SWO2
TIME
specified in the EN 12453 standard.
9.7) STATISTICS
Having connected the UNIPRO programmer to the control unit, enter the
CONTROL UNIT / STATISTICS menu and scroll the screenful showing the
statistical parameters:
- Board microprocessor software version.
- Number of cycles carried out. If motors are replaced, count the number
of manoeuvres carried out up to that time.
- Number of cycles carried out from the latest maintenance operation.
It is automatically set to zero after each self-diagnosis or parameter writing.
- Date of latest maintenance operation. To be updated manually from the
appropriate menu "Update maintenance date".
- Installation description. 16 characters can be entered for installation
identification.
10) INTEGRATED RECEIVER TECHNICAL SPECIFICATION
Receiver output channels:
- output channel 1, if activated, controls a START command.
- output channel 2, if activated, controls the excitation of the 2nd radio
channel relay for 1s.
Transmitter versions which can be used:
all Rolling Code transmitters compatible with

ANTENNA INSTALLATION

Use an antenna tuned to 433MHz.
For Antenna-Receiver connection, use RG8 coaxial cable.
The presence of metallic masses next to the antenna can interfere with radio
reception. In case of insufficient transmitter range, move the antenna to a
more suitable position.
11) RECEIVER CONFIGURATION
The on-board receiver combines characteristics of utmost safety in copying
variable code (rolling code) coding with the convenience of carrying out
transmitter "cloning" operations thanks to an exclusive system.
Cloning a transmitter means creating a transmitter which can be automatically
included within the list of the transmitters memorised in the receiver, either
as an addition or as a replacement of a particular transmitter.
Cloning by replacement is used to create a new transmitter which takes
the place of the one previously memorised in the receiver; in this way a
specific transmitter can be removed from the memory and will no longer
be usable.
Therefore it will be possible to remotely program a large number of additional
transmitters or, for example, replacement transmitters for those which have
been lost, without making changes directly to the receiver.
When coding safety is not a decisive factor, the on-board receiver allows
you to carry out fixed-code additional cloning which, although abandoning
the variable code, provides a high number of coding combinations, there-
= EXTERNAL START input activation
= INTERNAL START input activation
= input activation PEDESTRIAN
= OPEN input activation
= CLOSE input activation
= STOP input activation
= PHOT input activation
= activation of input for PHOTOCELL ON OPENING
= activation of input for PHOTOCELL ON CLOSING
= input activation SAFETY EDGE
= activation of input for MOTOR 1 CLOSING LIMIT SWITCH
= activation of input for MOTOR 1 OPENING LIMIT SWITCH
= activation of input for MOTOR 2 CLOSING LIMIT SWITCH
= activation of input for MOTOR 2 OPENING LIMIT SWITCH
= TIMER input activation
WARNING: Check that the impact force value measured at the
points established by the EN 12445 standard is lower than that
Incorrect sensitivity setting can cause injuries to persons or
animals, or damage to things.
.
