4 Technical specifications

Power Requirements
Supply Voltage
Primary Fuse
Current consumption
Connection
Power supply
Max. cable resistance per wire
Max. total cable length Standard
2
Simco 5x0,34 mm &
M12 Male-Female cable
Input
Remote on/off
Activation time
Output
Output voltage emitters
Current per emitter to earth
High voltage OK (HV OK)
Environment
Usage
Ex environment (See Chapter 3)
Protection class
Ambient temperature
Max. Temperature enclosure
Material (Speed)
Werking distance
Local signaling
2-Colour LED
Mechanical
Effective length
Dimensions exclusive
Mounting brackets
Weight
Enclosure
Universal Mounting brackets
PerformaxEasyExPerformaxEasyExSpeed_UM_9752153010_NL_D_ GB_FR_V2_3
24 V DC nominal
0,5 AT, Type: 70-007-65/0.5A, Siba
This fuse has a rupturing capacity of min. 1500A (breaking capacity).
This fuse is present in the delivered Ex Status Module by Simco-Ion.
Max. 0,4 A DC
2
Cable 5 x 0,34 mm
24V DC ± 2% 24V DC ± 5%
3,125Ω 2,25Ω
62,5m 45m
10 – 30 V DC nominal (Ri >10k)
30 ms
Max. 9 kV positive and negative
Max. 50 µA
Supply voltage -1 V, max. 50 mA
Industrial, indoor usage
ATEX II 2 GD
Ex mb IIB T4 Gb
Ex mb IIIB T135°C Db
IP66
0 - 40°C
135°C
Performax Easy Ex
Performax Easy Ex Speed
Performax Easy Ex
Performax Easy Ex Speed
Continual:
Green In use
Red Overloaded
See chapter 7 for more info
Performax Easy Ex
Performax Easy Ex Speed
Tot. length= Eff. length + 250 mm (with protective hose)
Tot. length= Eff. length + 180 mm (without protective hose)
Width 30 mm
Height 52 mm
2,2 kg/m
Aluminium / PA6 / PUR
PA66/6
24V DC ± 10%
0,75Ω
15m
IECEx BAS 17.0095X
Ex mb sb IIB T4 Gb
Ex mb sb IIIB T135°C Db
0 – 500 m/min
>500 m/min
100 - 300 mm
50 – 300 mm
Blinking:
Stand-by
HV OK overloaded
270 - 2790 mm
in increments of 180 mm
90 - 2790 mm
in increments of 60 mm
