OVEN AND ACCESSORIES

NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to
ensure that it is not damaged.
• Always operate the oven with the turntable and roller stay fitted correctly. This promotes
thorough, even cooking. A badly fitted turntable may rattle, may not rotate properly and
could cause damage to the oven.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each
time you start the oven. This does not affect cooking performance.
• When you order accessories, please quote both the PART NAME and MODEL NUMBER to
your dealer or SHARP approved service facility.
WARNING:
The door, outer cabinet, oven cavity, turntable and dishes will become very
hot during operation. To prevent burns, always use thick oven gloves.
OVEN
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Door opening button
6. Control Panel
7. Waveguide cover (DO NOT REMOVE)
8. Glass Turntable
9. Grill Heater
10. Grill Rack
• Place the roller stay in the coupling on the
oven floor, then place the turntable on to
the roller stay, ensuring it is located firmly.
• To avoid turntable damage, ensure dishes
or containers are lifted clear of the turn-
table rim when removing them from the
oven.
• For use of rack, refer to the sections on
grilling feature on page GB-26.
GB-3
