OVEN AND ACCESSORIES

1 Control panel
2 Door opening button
3 Waveguide cover
4 Seal packing
5 Oven cavity
6 Door
7 Door safety latches
8 Door hinges
9 Door seals and sealing surfaces
10 Oven lamp
11 Ventilation openings
12 Outer cabinet
13 Power cord
ACCESSORIES:
Check to make sure the following accessories are
provided:
(14) Turntable (15) Roller stay
• Place the roller stay in the seal packing on the
floor of the cavity.
• Then place the turntable on the roller stay.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
9
8
7 6 5 4
2
10
1
2
3
11
13
Seal packing
12
14
15
