5.3 Drilling without hammer action
Note
Drilling without hammer action is possible when accessory tools with a special connection end are
used. Tools of this kind are available from the Hilti tools range.
When the keyless quick-release chuck is fitted, smooth-shank drill bits for wood or steel, for example,
can be used to drill without hammer action.
▶ Set the function selector switch to the "Hammer drilling" position
5.4 Mixing 5
Note
Use the mixing paddle only with the quick-release chuck.
▶ Set the function selector switch to the "Hammer drilling" position
the quick-release chuck.
5.5 Setting the power level
TE 70-ATC/AVR
TE 80-ATC/AVR
Note
Power can be set only when the tool is switched on and ready for use.
To set the tool to half power, press the "half power" button. The power indicator lights up to indicate
reduced power. Press the "half power" button again to switch to full power. The power indicator goes
out.
Switching the combihammer off and then on again resets the tool to full power.
▶ Set the power level.
5.6 Drilling with hammer action (hammer drilling)
▶ Set the function selector switch to the "Hammer drilling" position
5.7 Chisel positioning
CAUTION
Risk of injury! Loss of control over the chisel direction.
▶ Do not operate the tool when the selector switch is set to "Chisel positioning". Turn the function
selector switch until it engages in the "Chiseling" position.
Note
The chisel can be set to 24 different positions (in 15° increments). This ensures that flat chisels and
shaped chisels can always be set to the optimum working position.
▶ Set the function selector switch to the "Chisel positioning" position
5.8 Chiseling 5
▶ Set the function selector switch to the "Chiseling" position
5.9 Control switch lock
Note
When chiseling, the control switch can be locked in the "on" position.
▶ Press the control switch lock.
Printed: 10.11.2017 | Doc-Nr: PUB / 5150798 / 000 / 05
5
5
.
and insert the mixing paddle into
5
.
.
.
English 7
