Tunturi R20 Rower Manuel De L'utilisateur page 70

F-20
Buble Description
1 Frame
2 Front foot
3 Pedal support
4 Right pedal
5 Left pedal
6 Rail tube
7 Rear foot
8 Seat
9 Locking knob
10 User interface
11 Hex head screw
12 Washer
13 Hex head screw
14 Washer
15 Bolt
16 Nylock nut
17 Hex head screw
18 Spring washer
19 Washer
20 Stopper
21 End cap
22 Washer
23 Axle
24 cap
25 Hexagon socket cap
screws
26 Axle
27 Sensor wire
28 Seat roller
29 Seat frame
30 Bolt
31 Middle rubber foot
32 End cap
33 Tension controller
34 Cap, foot tube
35 Nylon nut
36 Transport wheel
37 Hex head screw
38 Height Adjustment
screw
39 Console bracket
40 Screw
41 Side cover(Left)
42 Side cover(Right)
43 Top cover
44 Handle bar stopper
45 Screw cover
46 Handle bar grip
47 Handle bar
48 Rope
Size Qty
1
1
1
1
1
1
1
1
1
1
M10*55 2
M10 Ø10.5* 4
Ø25*T1.5
ISO 7380 M6*15 10
M6 Ø6.5*Ø20* 6
T1.5T1.5
M10*50 2
M10 2
M8*20 9
M8 Ø8 4
M8 Ø8.5* Ø16*T1.5 16
4
1
M6Ø6.5* Ø16*T1.5T 5
Ø10*102.5 2
1
M8*80 1
Ø13*156 2
1
4
1
M6*40 3
1
2
1
1
M8 9
2
M8*40 2
2
1
M5*15 16
1
1
1
1
2
2
1
1
7 0
49 Locking plate
50 Spring assembly
51 Rope pulley
52 Axle
53 Bearing
54 Flywheel
55 Flywheel adjuster
56 Belt
57 Pedal stopper
58 Screw
59 Bracket
60 Bolt
61 Rubber ring
62 Arc washer
63 Rear rubber foot
64 Bolt
65 Axle
66 Rataining ring
67 Foot strap
68 Spring
69 Pedal stopper
Wrench
Wrench
Wrench
Wrench
1
1
1
Ø10*41 4
6000Z 2
1
2
1
2
M5*10 1
1
M5*25 1
1
Ø16*Ø8.5* T1.5 1
1
M5*10 6
Ø18*11* Ø12*5.8 4
8mm 4
2
Ø3*Ø16.5* 16.0 1
2
L6 1
L6 1
L13-L17 1
L4 2
