  6. Manuel d'utilisation

REED R7900 Manuel D'utilisation

Masquer les pouces
Table des Matières

Publicité

Les langues disponibles

Les langues disponibles

Liens rapides

Télécharger ce manuel
Rich Black -
20/20/20/100
R7900
Model
Ultrasonic Thickness Gauge
Only if you REALLY need them:
Instruction Manual
reedinstruments
www
com
REED Instruments
1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com

Publicité

Chapitres

Table des Matières
loading

Manuels Connexes pour REED R7900

Sommaire des Matières pour REED R7900

  • Page 1 Rich Black - 20/20/20/100 R7900 Model Ultrasonic Thickness Gauge Only if you REALLY need them: Instruction Manual reedinstruments REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...

  • Page 2: Table Des Matières

    Utilization and Selection of a Coupling Agent......16 Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow continued ... Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 3: Features

    For use in petroleum, chemical, metallurgy, shipping, aerospace, Red - 10/100/100/5 aviation, and other fields 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 4: Specifications

    Minimum Area: ø20×3mm Red - 10/100/100/5 485 Red Applications: General Straight Probe Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...
  • Page 5 123 Yellow Teflon 1422 0.058 Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 Water 1473 0.058 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 6: Instrument Description

    123 Yellow Save File Name Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Menu Option Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 7: Operating Instructions

    123 Yellow readouts as the measured thickness. Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 8: Taking Thickness Measurements

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 9: Sound Velocity Measurements

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 10: Minimum Capture Measurements

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 11: Measurement Methods

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 12: Measuring Compound Profiles

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 13: Measuring Castings

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 14: Preventing Errors

    Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow rough measurement. Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 15: Ultra-Thin Material

    Red - 10/100/100/5 485 Red ultrasonic thickness-gauge to measure overlapped material and Yellow - 0/27/100/0 123 Yellow compound material. Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 16: Influence Of Metal Surface Oxidation

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 17: Menu Options

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 18: Print Function

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 19: Internal Memory Operation

    The probe cannot take measurements when the temperature of the Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow surface to be measured exceeds 60°C. Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 20: Changing The Probe

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...
  • Page 21 534 Blue Yellow - 0/27/100/0 123 Yellow ________________________________________________ Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...
  • Page 22 534 Blue Yellow - 0/27/100/0 123 Yellow ________________________________________________ Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...
  • Page 23 Rich Black - 20/20/20/100 R7900 Modèle Jauge d’épaisseur Only if you REALLY need them: ultrasonique Manuel d’utilisation reedinstruments REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
  • Page 24 Utilisation et sélection d’un agent de couplage ......17 Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow suite... Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 25: Caractéristiques

    Red - 10/100/100/5 autres domaines 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 26: Spécifications

    Yellow - 0/27/100/0 123 Yellow Applications: sonde droite générale Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 27: Vélocité Sonore Pour Les Différents Matériaux

    123 Yellow Téflon 1422 0.058 Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 1473 0.058 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 28: Description De L'instrument

    Enregistrement du nom de fichier Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Option de menu Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 29: Mode D'emploi

    Yellow - 0/27/100/0 123 Yellow perpendiculaire ou parallèle. Prendre la valeur minimale des lectures comme l’épaisseur mesurée. Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 30: Prise De Mesure D'épaisseur

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 31: Mesures De Vélocité Sonore

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 32: Capture Des Mesures Minimales

    Appuyer sur le bouton entrée (Enter) lorsque l’opération de Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow calibrage est terminée Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 33: Méthodes De Mesure

    Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 34: Mesure De Profilé Composite

    123 Yellow être mesurés avec cet appareil. Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 35: Mesure Des Moulages Par Coulée

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 36: Prévention Des Erreurs

    485 Red l’intérieur doit aussi être la même que celle dans l’objet. Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 37: Matériau Ultra-Mince

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 38: Dégradation De La Sonde

    Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 39: Utilisation Et Sélection D'un Agent De Couplage

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 40: Options Des Menus

    485 Red Yellow - 0/27/100/0 123 Yellow haut et/ou vers le bas pour ajuster Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 41: Fonction D'impression

    Efface toutes les données de calibrage Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 42: Restaurer Les Valeurs D'usine Par Défaut

    534 Blue Yellow - 0/27/100/0 123 Yellow Red - 10/100/100/5 485 Red Yellow - 0/27/100/0 123 Yellow Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...

  • Page 43: Maintenance

    Yellow - 0/27/100/0 123 Yellow on doit retirer les piles pour éviter leur coulage et de la corrosion Blue - 100/80/30/5 534 Blue reedinstruments Rich Black - REED Instruments 20/20/20/100 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com Only if you REALLY need them:...
